Products

New Products

LGA1151 1+1 Power Supply 1U Firewall Appliance

♦Model NO.:ST-C2468L-2P V1.0

♦1U Standard Rack_mount Chassis

♦Intel Socket LGA1151 processors

♦2x DDR4 RAM slot, up to 32GB

♦4x SATA3.0 + 1x MSATA + 1x M.2

♦8x 2.5GbE Ports (RJ45)

♦2x PCI-E x8 (SFP+ Expansion)

♦(Bypasss/Vpro) Optional

♦1x Mini-pcie&M.2 (Wifi&BT&4G/5G LTE)

♦2x USB3.0 ; 4x USB2.0(inner)

♦1+1 Redundant Power Supply (Hot_Swap)
4 Lan N100 2x SFP+ (10Gb) Firewall MIni Router

♦Model NO.:ST-AD12N-6S V1.0

♦Aluminum Alloy ; Active Cooling

♦Intel N97/N100/N200/N305 CPUs

♦1x DDR5 RAM slot, up to 32GB

♦1x SATA3.0 + 1x M.2 NVMe X1 + 1x TF slot

♦4x 2.5GbE RJ45 + 2x SFP+ (10Gb)

♦DP+HDMI+Type_C Triple Display

♦1x Mini-PCIe for 4G LTE

♦1x SIM slot

♦5x USB2.0 ; 1x USB3.0

♦DC_12V Power Input
23.8 inch RK3588 Android Industrial Tablet PC support 5G module

♦Support RK3588, Octa-core 64-bit (4×Cortex-A76+4×Cortex-A55) at 2.4GHz CPU

♦Capacitive / Resistive touch:23.8" TFT LCD / 1920*1080 / 250 cd/m²

♦3mm Super Thin Front Bezel, Best for Embedded Cabinet.

♦Pure flat panel IP65 dust-proof and waterproof.

♦RK3588 eight-core high-end CPU ，Built-in independent NPU with 6TOPS AI computing power

♦6TOPS AI computing power

♦Support 8K ultra-high definition display, support double display,can be customized four display

♦Provide SDK package, support secondary development and upgrade customization
15.6 inch RK3588 Android Industrial Tablet PC support 5G module

♦Support RK3588, Octa-core 64-bit (4×Cortex-A76+4×Cortex-A55) at 2.4GHz CPU

♦Capacitive / Resistive touch:15.6" TFT LCD / 1920*1080 / 300 cd/m²

♦3mm Super Thin Front Bezel, Best for Embedded Cabinet.

♦Pure flat panel IP65 dust-proof and waterproof.

♦RK3588 eight-core high-end CPU ，Built-in independent NPU with 6TOPS AI computing power

♦6TOPS AI computing power

♦Support 8K ultra-high definition display, support double display,can be customized four display

♦Provide SDK package, support secondary development and upgrade customization

6 Lan J1900 firewall motherboard

♦Model No.: D19SL VER:1.0

♦Based on Intel Bay trail SOC platform

♦Integrated Intel Celeron J1900 2.0GHz quad core processor

♦Integrated Intel HD Graphics ; 1*VGA for Display

♦1*DDR3L 1600/1333 MHz SO-DIMM Socket, up to 8GB memory.

♦2*SATA2.0 / 1*mSATA 2.0 SSD / 2*mini-pcie(Wifi/3G/4G) / 1* SIM slot

♦6*RJ45- Intel I210AT Gigabit Ethernet (Bypass optional)

♦6*USB2.0 / 1*RJ45 RS232(CISCO standard) / 1*PS2

♦Provide: 1* DC_Jack 12V Input ; 1*ATX 4pin 12V input (fanless)

Read More Make an inquiry
6 Lan J4125 firewall motherboard

♦Model No.: D41SL VER:1.0

♦Based on Intel Gemini Lake SOC platform

♦Integrated Intel Celeron J4125 2.0GHz Quad core processor

♦Integrated Intel HD Graphics 600 ; 1*VGA for Display

♦1*DDR4 2400MHz SO-DIMM Socket, up to 8GB memory

♦2*SATA3.0 / 1*mSATA SSD / 2*mini-pcie(Wifi/3G/4G) / 1* SIM slot

♦6*RJ45- Intel I226V 2.5G Ethernet ports (Bypass optional)

♦6*USB2.0 / 2*Serial port (RS232) / 1*PS2

♦Provide: 1* DC_Jack 12V Input ; 1*ATX 4pin 12V input (fanless)

Read More Make an inquiry
6 Lan 2 Bypass J4125 firewall motherboard

♦Model No.: D41SL_B VER:1.0

♦Based on Intel Gemini Lake SOC platform

♦Integrated Intel Celeron J4125 2.0GHz Quad core processor

♦Integrated Intel HD Graphics 600 ; 1*VGA for Display

♦1*DDR4 2400MHz SO-DIMM Socket, up to 8GB memory.

♦2*SATA3.0 / 1*mSATA SSD / 2*mini-pcie(Wifi/3G/4G) / 1* SIM slot

♦6*RJ45- Intel I226V 2.5G Ethernet ports ( with 2*Bypass )

♦6*USB2.0 / 2*Serial port (RS232) / 1*PS2

♦Provide: 1* DC_Jack 12V Input ; 1*ATX 4pin 12V input (fanless)

Read More Make an inquiry
6 Lan Bypass optional J6412 firewall motherboard

♦Model No.: D641SL VER:0.1

♦Based on Intel Elkhart Lake SOC platform

♦Integrated Intel Celeron J6412 2.0~2.6GHz quad core processor

♦Integrated Intel UHD Graphics ; VGA+HDMI for Display

♦1*DDR4 2400MHz SO-DIMM Socket, up to 16GB memory.

♦1*SATA3.0 / 1*mSATA SSD / 1*mini-pcie(Wifi) / 1* M.2(5G)+SIM slot

♦6*RJ45- Intel I226V 2.5G Ethernet ports (Bypass optional)

♦6*USB / 2*COM RS232(1*Console) / 1*PS2

♦Provide: 1* DC_Jack 12V Input ; 1*ATX 4pin 12V input (fanless)

Read More Make an inquiry
4 Lan Atom D525 firewall motherboard

♦Model No.: ITX-M5V VER:1.3

♦Based on Intel® 8201HBM Express Chipset.

♦Integrated Intel Atom D525 1.80GHz dual core processor

♦Integrated Intel® G3150 Graphic ; 1*VGA for Display

♦1*SO-DIMM DDR3 1066/800MHz Socket, up to 2GB memory.

♦4*RJ45-82583V Gigabit Ethernet / 6*USB2.0 / 2*RS232 / 1*PS2

♦2*SATA2.0 / 1*mSATA 2.0 SSD / 1*mini-pcie(Wifi/3G/4G) /1* SIM slot

♦Support GPIO ; Watchdog ; 1*PCI slot

♦Provide: 1* DC_Jack 12V Input ; 1*ATX 4pin 12V input

Read More Make an inquiry
4 Lan J1900 firewall motherboard

♦Model NO.: ITX-M9F VER:1.5

♦Based on Intel Bay trail SOC platform

♦Integrated Intel Celeron J1900 2.0GHz quad core processor

♦Integrated Intel HD Graphics ; 1*VGA for Display

♦1*DDR3L 1600/1333 MHz SO-DIMM Socket, up to 8GB memory.

♦2*SATA2.0 / 1*mSATA 2.0 SSD / 1*mini-pcie(Wifi/3G/4G) /1* SIM slot

♦4*RJ45-RTL82583V / 82574L Gigabit Ethernet (Bypass optional)

♦6*USB2.0 / 1*RJ45 RS232(CISCO standard) / 1*PS2

♦Provide: 1* DC_Jack 12V Input ; 1*ATX 4pin 12V input (fanless)

Read More Make an inquiry
4 Lan J4125 firewall motherboard

♦Model No.: ITX-M41V VER:1.1(J4125)

♦Based on Intel Gemini Lake SOC platform

♦Integrated Intel Celeron J4125 2.0GHz Quad core processor

♦Integrated Intel HD Graphics 600 ; 1*VGA for Display

♦1*DDR4 2400MHz SO-DIMM Socket, up to 8GB memory.

♦2*SATA2.0 / 1*mSATA 2.0 SSD / 1*mini-pcie(Wifi/3G/4G) / 1* SIM slot

♦4*RJ45- Intel I225V 2.5G Ethernet ports (Bypass optional)

♦6*USB2.0 / 1*RJ45 RS232(CISCO standard) / 1*PS2

♦Provide: 1* DC_Jack 12V Input ; 1*ATX 4pin 12V input (fanless)

Read More Make an inquiry
6 Lan LGA1200 firewall motherboard

♦Model No.: Q570SL_6L VER:1.1

♦Based on Intel Q570 express chipset.

♦Support LGA1200 socket Intel Celeron/Pentium/Core i3/i5/i7/i9 processors

♦Integrated Intel® HD Graphics ; VGA for Display

♦4*DDR4 UDIMM 3200MHz Socket, up to 128GB memory.

♦6*Intel® WGI210AT Gigabit Ethernet；

♦1*Intel®KTI226LM Gigabit Ethernet (support VPro)

♦4*SATA3.0 / 3*M.2(SSD/4G/5G/WIFI) / 2*PCIE X8 slot

♦4*USB2.0 / 2*RS232 / 1*TPM / 1*SIM Card slot / 1*FPC

♦Support Watchdog ; ATX power Input

Read More Make an inquiry
4 Lan J1900 firewall motherboard

♦Model No.: STX-R19E VER:1.0

♦Based on Intel Bay trail SOC platform

♦Integrated Intel Celeron J1900 2.0GHz quad core processor

♦Integrated Intel HD Graphics ; VGA Display

♦1*DDR3L 1600/1333MHz SO-DIMM Socket, up to 8GB memory.

♦1*SATA2.0/ 1*mSATA 2.0 SSD / 1*mini-pcie(Wifi/3G/4G) / 1* SIM slot

♦4*RJ45- Intel WGI210AT Gigabit Ethernet

♦2*USB2.0 / 1*USB3.0 / 1*COM RS232(CISCO standard) / 1*PS2

♦Support GPIO ; Watchdog Timer ; 1* DC_Jack 12V / ATX 4pin input

Read More Make an inquiry
4 Lan J4125 firewall motherboard

♦Model No.: STX-R41E VER:1.0

♦Based on Intel Gemini Lake SOC platform

♦Integrated Intel Celeron J4125 2.0GHz Quad core processor

♦Integrated Intel HD Graphics 600 ; 1*VGA for Display

♦1*DDR4 2400MHz SO-DIMM Socket, up to 8GB memory.

♦1*SATA2.0/ 1*mSATA 3.0 SSD / 1*mini-pcie(Wifi/3G/4G) / 1* SIM slot

♦4*RJ45- Intel WGI210AT Gigabit Ethernet

♦2*USB2.0 / 1*USB3.0 / 1*COM RS232(CISCO standard) / 1*PS2

♦Support GPIO ; Watchdog Timer ; 1* DC_Jack 12V / ATX 4pin input

Read More Make an inquiry
4 Lan J4125 firewall motherboard

♦Model No.: STX-R41V VER:1.1(J4125)

♦Based on Intel Gemini Lake SOC platform

♦Integrated Intel Celeron J4125 2.0GHz Quad core processor

♦Integrated Intel HD Graphics 600 ; 1*HDMI for Display

♦1*DDR4 2400MHz SO-DIMM Socket, up to 8GB memory.

♦1*mSATA 3.0 SSD / 4*USB3.0

♦4*RJ45- Intel WGI210AT Gigabit Ethernet

♦1*120pin express Expansion slot for (SATA / Mini-PCIE / 2*TTL / USB )

♦Support GPIO ; Watchdog Timer ; 1* DC_Jack 12V / ATX 4pin input

Read More Make an inquiry
8 Lan LGA1200 firewall mtoerhboard

♦Model No.: W580SL_8L VER:1.5

♦Based on Intel W580 express chipset.

♦Support socket LGA1200 Intel Celeron/Pentium/Core i3/i5/i7/i9 processors

♦Integrated Intel® HD Graphics ; VGA for Display

♦4*DDR4 UDIMM 3200MHz Socket, up to 128GB memory.

♦8*Intel® WGI210AT Gigabit Ethernet；

♦1*Intel®KTI226LM Gigabit Ethernet (support VPro)

♦4*SATA3.0 (support RAID 0,1,5,10) / 3*M.2 slot (SSD/4G/5G/WIFI)

♦4*USB / 2*RS232 / 1*TPM / 1*SIM slot / WDT / 2*PCIE X8 slot

♦ATX power Input

Read More Make an inquiry
