Overview
The RK3576 is a high - performance, low - power application processor chip with an advanced 8nm manufacturing process. It features an 8 core, 64 bit core architecture. The four A72 big cores can have a main frequency of up to 2.2GHz, and the four A53 small cores can have a main frequency of up to 1.8GHz. It is equipped with an NPU with 6TOPS of AI computing power, and the GPU uses the ARM Mali G52 MC3.
Functions
The SII-3576 - A is equipped with the RK3576, running Android 14, Linux 6.1, Debian 12, and Ubuntu 22.04 systems. It has on-board LVDS, eDP, MIPI, and HDMI display output interfaces, a built-in universal backlight board interface, and screen voltage jumpers, which are compatible with more types of display screens. It has stronger performance, faster speed, and richer interfaces, making it the best choice for HMI, intelligent terminals, and industrial control projects.
Features
Rich expansion interfaces: 6 USB interfaces (1 USB 2.0 standard interface, 1 SUB3.0 OTG interface, and 4 USB 2.0 sockets), 1 RS485 interface, 1 TTL interface, 2 RS232 interfaces, 2 interfaces that can be switched between RS232/RS485 via jumpers, 8 GPIO interfaces, and1 ADC interface, which can meet the requirements of various peripherals on the market.Multiple network interfaces: 1 1000M Ethernet interface, supporting 5G and 2.4G WIFI, anda built - in MINI PCIE - standard 4G module interface, supporting Internet access and calls.High definition: HDMI supports a maximum output of 4096x2160@120Hz, supports LCD display screens and cut - off screens of LVDS/eDP/MIPI/HDMI interfaces, and supports multi - screen different - display.
It supports Android system customization, provides system calling interface API reference code, and perfectly supports customers upper layer application APP development.
Application
We have a comprehensive layout in the fields of smart loT and cloud computing.Our products have been widely used in industrial equipment automation (intelligent manufacturing), self-service terminal, network security, digital signage, medical equipment (medical imaging), intelligent terminal, intelligent transportation, cloud server, cloud storage, machine vision, robot, intelligent kiosk, GPS navigation, instrumentation, Government agencies, telecommunications, banking, electricity, vehicle automation (control and display), monitors, video doorbells, portable computers, intelligent teaching, environmental protection equipment, etc.
Packing & Delivery
We have a wide range of transportation options to choose from. No matter where you are, our transportation options can meet your needs.
Company Profile
FAQ
Q1.Do you accept OEM / ODM order?
A1: Of course, we have our own R&D team that support customization on motherboard design, test and produce.
Q2: What payment method do you accept?
A2:We accept T/T,MoneyGram,Paypal, Western Union is all ok.
Q3:How long is the warranty of your products?
A3:we offer 2 years warranty for all of our products.
Q4:How many days will samples be finished? And how about the mass production?
A4:Samples will be deliver within 3 working days,after payment received. The leading time of mass production will depend on the quantity.
Q5:If we come to China,can you arrange the visiting to your factory?
A5:We warmly welcome and look forward to your visiting to our factory at any time.
