Products

New Products

4 Lan N97 DDR4 Fanless Mini Firewall

♦Model No.:C2120Z-L4 V2.0(N97)

♦All aluminum alloy, fanless cooling structure

♦Intel®Alder Lake-N N97/Turbo 3.6GHz quad-core CPU

♦1x DDR4 RAM slot, up to 16GB

♦1x SATA + 1x M.2

♦4x RJ45 Lan

♦1x HDMI1.4

♦1x Mini-PCIe for 4G/WIFI

♦5x USB3.0, 1x USB2.0

♦DC_12V Power Input
8 Lan LGA1151 DDR4 SFP Pfsense Firewall System Security

♦ Model No.:R320E-L8 V1.0(R270)

♦ Intel®LGA1151 6th/7th/8th/9th i3/i5/i7 series processor

♦ Intel®Q270/Q250 High speed chipset

♦ 2*DDR4 SODIMM 2400MHz ,max up to 64GB

♦ 8*Intel I210 Gigabit Ethernet port，4 or 2 SFP+ ports can be extended

♦ 2*USB3.0, 1*VGA

♦ 4 or 2 light ports can be extended

♦ Support two groups of BYPASS(Optional)

♦ Standard with 1U AC220V ATX power supply 250W

♦ 1U standard case, high-quality galvanized steel plate / Support Windows&Linux OS
4 Lan N97 DDR4 Machine Vision Motherboard

♦Model No.:ITX-VL305 VER:1.0(N97)

♦Based on Inte Alder Lake-N SOC platform

♦Integrated Intel®Alder Lake-N N97 3.6GHz quad-core processor

♦Intel® UHD Graphics; VGA+HDMI+LVDS/1* EDP for display

♦1*DDR4 2133MHz SO-DIMM Socket, up to 16GB

♦4* Intel WGI210AT Gigabit Ethernet/ 8*USB/ 6*COM /1*SIM/ 1* TPM

♦1*SATA3.0/ 1* M.2 SSD/ 1* Mini-PCIE (Wifi/4G)

♦Support GPIO ; Watchdog Timer ; Audio power amplifier 4Ω/3W

♦Support DC_12V Input
RK3576 ARM Motherboard

♦Model No.:CX3576-A V1.0 (4G+128G) VER:4G

♦WIFI use FCS960K,support 2.4G/5G dual-band,Bluetooth5.3

♦Bottom plate thread DC2.0*1（12V-36V input)

♦RJ45*1、HDMI*1、USB3.0*1、USB2.0*1、USB2.0 socket*4、TF*1、Audio 3.5mm*1

♦Size:157*100mm

J3455 thin itx motherboard

♦Model No.: ITX-B347_J112L VER:1.2

♦Based on Intel Apollo Lake SOC platform

♦Integrated Celeron J3455 1.50GHz Quad core processor

♦Intel HD Graphics 500 ; VGA + HDMI + LVDS for Display

♦1*DDR3L 1600/1866MHz SO-DIMM Socket, up to 8GB

♦1*RJ45 Gigabit Eth / 10*USB / 2*COM(RS232/485/422) / 1*SIM slot

♦1*SATA2.0 / 1*mSATA SSD / 1*mini-pcie(Wifi/3G/4G) / 1*LPT / 1*PS2

♦Support GPIO ; Watchdog Timer ; SPK 2Ω/5W

♦Provide: 1* DC_Jack 12V Input ; 1*DC 2pin 12V input (Fanless)

Read More Make an inquiry
J3455 thin itx motherboard

♦Model No.: ITX-B346_J116L VER:1.1(J3455)

♦Based on Intel Apollo Lake SOC platform

♦Integrated Celeron J3455 1.50GHz Quad core processor

♦Intel HD Graphics 500 ; VGA + HDMI + LVDS for Display

♦1*DDR3L 1600/1866MHz SO-DIMM Socket, up to 8GB

♦1*RJ45 Gigabit Eth / 10*USB / 6*COM(RS232/485/422) / 1*SIM slot

♦1*SATA2.0/1*mSATA SSD/ 1*M.2 SSD / 1*mini-pcie(Wifi/3G/4G)

♦Support GPIO ; Watchdog Timer ; SPK 2Ω/5W ; 1*LPT

♦Provide: 1* DC_Jack 12V Input ; 1*ATX 4pin 12V input (Fanless)

Read More Make an inquiry
2 Lan LGA1700 1U Server

♦Model No.: R570H-E1 V1.0 (LGA1700)

♦Socket LGA1700 12/13/14th Gen Intel processors (up to: 125W)

♦2x SO-DIMM DDR4 RAM slot,up to 64Gb

♦2x RJ45 2.5G Ethernet ports(Intel I226V )

♦6x RS232 DB9 ports (support RS232/485/422)

♦4x USB3.0 ; 4x USB2.0 ; 1x PS/2 (K&B)

♦2x SATA3.0 + 1x M.2 Key_M 2260/2280 NVMe/SATA SSD

♦1x PCI_E3.0 X16 slot for expansion

♦Built-in 1U ATX FLex power supply

Read More Make an inquiry
2 Lan i5-3210M pfsense firewall hardware

♦Model No.: R280H V1.0(B320)

♦1U standard Rackmount, high quality galvanized steel plate

♦Integrated Intel Core i5-3210M/2.5GHz (2 core 4 threads) processor

♦Display: 1x VGA + 1x HDMI

♦Memory: 1x DDR3 1600/1333MHz SO-DIMM socket, up to 8GB

♦Ethernet: 2x RJ45 GbE LAN (PXE/WoL) / 1x MINI-PCIE (WIFI/3G/4G)

♦1x SATA 2.5‘‘/ 1x MSATA

♦2x USB2.0 / 2x USB3.0 / 6x COM port (RS-232/422/485) / WDT

♦ATX/1U Power Supply (AC_100-240V) / Support Windows&Linux OS

Read More Make an inquiry
6 Lan J1900 pfsense firewall hardware

♦Model NO.: R19SLZ V:1.0

♦1U standard Rackmount, high quality galvanized steel plate

♦Integrated Intel Celeron J1900 2.0GHz (4 core 4 threads) processor

♦Display: 1x VGA

♦Memory: 1x DDR3L 1600/1333MHz SO-DIMM socket, up to 8GB

♦Ethernet: 6x RJ45 GbE LAN (support PXE/WoL) / 2x MINI-PCIE (WIFI/3G/4G)

♦1x SATA 2.5‘‘/ 1x MSATA

♦2x USB2.0 / 1x RJ45 console port (RS-232) / WDT

♦ATX/1U Power Supply (AC_100-240V) / Support Windows&Linux OS

Read More Make an inquiry
6 Lan J4125 pfsense firewall hardware

♦Model NO.: R41SLZ V1.0(J4125)

♦1U standard Rackmount, high quality galvanized steel plate

♦Integrated Intel®Celeron J4125/2.0GHz quad core quad thread processor

♦Display: 1x VGA

♦Memory: 1*SODIMM DDR4 2400MHz RAM,is up to 8GB

♦Ethernet: 6x RJ45 GbE LAN / 2x MINI-PCIE (WIFI/4G)

♦1x SATA 2.5‘‘/ 1x MSATA

♦2x USB2.0 / 1x RJ45 console port (RS-232)

♦ATX/1U Power Supply (AC_110-240V) / Support Windows&Linux OS

Read More Make an inquiry
6 Lan LGA1151 2 or 4x SFP 10 GbE pfsense firewall hardware network appliance

♦Model No.: R320V-SF V1.0(R270)

♦1U standard Rackmount, high quality galvanized steel plate

♦Support LGA1151 6th~9th Celeron/Pentium/Core i3/i5/i7/i9 processors

♦Display: 1x VGA

♦Memory: 2x DDR4 2400MHz SO-DIMM socket, up to 64GB

♦Eth: 6x RJ45 2.5GbE LAN + 2/4x SFP+ Fiber/COPPER ports (1/10 GbE ) ; Bypass Optional

♦1x SATA / 1x MSATA / 1x PCIE X8 / 1x M.2(WiFi) / 1x M.2(5G) / 1x TPM-4 COM

♦2x USB2.0 / 1x USB (for Security Dongle) / 1x RJ45 console port (RS-232) / WDT

♦ATX/1U Power Supply (AC_100-240V) / Support Windows 7 / 10 &Linux UbuntuOS

Read More Make an inquiry
6 Lan J4125 pfsense firewall hardware

♦Model NO.: R41SLZ-B V1.0(J4125)

♦1U standard Rackmount, high quality galvanized steel plate

♦Integrated Intel®Celeron J4125/2.0GHz quad core quad thread processor

♦Display: 1x VGA

♦Memory: 1*SODIMM DDR4 2400MHz RAM,is up to 8GB

♦Ethernet: 6x RJ45 GbE LAN / 2x MINI-PCIE (WIFI/4G)

♦1x SATA 2.5‘‘/ 1x MSATA

♦2x USB2.0 / 1x RJ45 console port (RS-232)

♦ATX/1U Power Supply (AC_110-240V) / Support Windows&Linux OS

Read More Make an inquiry
4 Lan 2.5G J4125 Pfsense Firewall Hardware

♦Model NO.: R41VUZ V1.0(J4125)

♦1U standard Rackmount, high quality galvanized steel plate

♦Integrated Intel®Celeron J4125/2.0GHz (4 core 4 threads) processor

♦Display: 1x VGA

♦Memory: 1x DDR4 2400MHz SO-DIMM socket, up to 8GB

♦Ethernet: 4x RJ45 GbE LAN (PXE/WoL) / Bypass Optional

♦1x SATA 2.5‘‘/ 1x MSATA/ 1x MINI-PCIE (WIFI/3G/4G)

♦2x USB2.0 / 1x RJ45 console port (RS-232) / WDT

♦ATX/1U Power Supply (AC_100-240V) / Support Windows&Linux OS

Read More Make an inquiry
6 Lan J6412 pfsense firewall hardware

♦Model No.: R641SLZ V1.0(J6412)

♦1U standard Rackmount, high quality galvanized steel plate

♦Integrated Intel® Celeron J6412/2.00GHz quad-core quad-thread processor ,TDP 10W

♦Display: 1x VGA

♦Memory: 1x DDR4 2400MHz SO-DIMM socket, up to 16GB

♦Ethernet: 6x RJ45 GbE LAN (support PXE/WoL) / 1x MINI-PCIE (WIFI)

♦1x SATA 2.5‘‘/ 1x MSATA

♦3x USB2.0 / 1x USB3.0 / 1x RJ45 console port (RS-232) / WDT

♦ATX/1U Power Supply (AC_100-240V) / Support Windows&Linux OS

Read More Make an inquiry
2 Lan 2 HDMI LGA1151 industrial ATX motherboard

♦Model No.: Z370VM VER:1.0

♦Adopt Intel Z370 Express chipset

♦Support LGA1151 6th~9th Gen Pentium/Core i3/i5/i7 processors

♦Integrated Intel HD Graphics ; 2*HDMI + VGA for display

♦4*DDR4 2133/2400/2666MHz DIMM socket, up to 64GB

♦2*RJ45 Gigabit Eth / 11*USB / 6~10*COM(RS232/485/422) / 2*PS2

♦4*SATA3.0 / 1*mSATA / 1*M.2 (NVMe PCIE x4) / 1*M.2 for 4G/5G

♦1*PCIE3.0 x16 ; 1*PCIE3.0 x1 ; 3*PCIE3.0 x4 ; 2*PCI ; 1*LPT ; 1*TPM

♦1*Mini-pcie (Wifi/TPM-4COM) ; 1* ATX 24PIN / 1*ATX 8pin input

Read More Make an inquiry
2 Lan 2 HDMI LGA1150 industrial ATX motherboard

♦Model No.: Q86M3 VER:1.0

♦Adopt Intel Q86 Express chipset

♦Support LGA1150 socket 4th Gen Intel Pentium/Core i3/i5/i7 processors

♦Integrated Intel HD Graphics ; 2*HDMI + VGA for display

♦2*DDR3 DIMM 1600/1333MHz Socket, up to 16GB memory

♦2*RJ45 Gigabit Ethernet / 11*USB / 6~10*COM(RS232/485/422)

♦2*SATA3.0 / 1*mSATA / 1*mini-pcie for (Wifi/TPM-4COM)

♦1*PCIE2.0 x16 ; 1*PCIE2.0 x4 ; 2*PCI slot ; 1*LPT ; 2* PS2 ; 1*WDT

♦Provide: 1* ATX 24PIN Input ; 1*ATX 8pin input

Read More Make an inquiry
