As a professional Industrial Panel PC Manufacturer, we introduce this Embedded Touch Screen PC supporting Intel i3 processors (i3-6100U/8145U/10110U), featuring precision aluminum alloy casing and self-developed fanless X86 industrial motherboard for cost-sensitive industrial applications.
Key Features:
✔ Cost-effective Display: 23.8" TFT LCD with 1920×1080 resolution, 250cd/m² brightness, supports capacitive/resistive dual-touch
✔ Military-grade Protection: 3mm ultra-narrow bezel, high-precision aluminum alloy, IP65 rating, flat front panel
✔ Industrial Reliability: 12V-36V wide voltage input, dual gigabit Ethernet ports, rich I/O interfaces
✔ Silent Fanless Operation: Self-developed motherboard for -20℃~60℃ wide temperature
✔ Embedded Installation: Optimized for cabinet mounting
Product Description
The overall use of flat aluminum alloy panel, fanless fully enclosed integrated design. Meet the requirements of different equipment in different environments. It is widely used in industrial control, military, communication, power, network, intelligent self-service terminal equipment and other automation applications.
Product Size: 23.8”
Non-touch: TPC238-W1000-I3
Capacitive touch: TPC238-W1010-I3
Resistive touch: TPC238-W1020-I3
Screen Parameters:
LCD Size: 23.8" TFT LCD
Resolution: 1920*1080
Viewing Angle: 89/89/89/89 (L/R/U/D)
Colour: 16.7M
Brightness: 250 cd/m2
Contrast ratio: 1000:1
Physical Characteristics:
Overall dimensions: W606 x H376 x D67mm
Size of opening: W589.8 x H359.8mm
Interface:
DC: 1*DC 2.5
HDMI: 1*HDMI, Support HDMI data output, maximum support 1080P
USB: 2*USB 2.0,2*USB 3.0
LAN: 2*LAN,Dual 1000M adaptive Ethernet
AUDIO: 1*Audio I/O,Support audio input and output
SMI card: Standard SIM card interface, supporting various standards (depending on 3G/4G module)
VGA: 1*VGA
RS232: 2*RS232(Optional RS485,RS422,GPIO)
POWER: 1*POWER
Industrial terminal: 1*Industrial terminal
Product Reliability:
Working Temperature: -10°C to 60°C
Storage temperature: -20°C to 70°C
Relative humidity: Humidity: 95% Non-Condensing
Vibration protection: IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
Impact protection: IEC 60068-2-27, half sine wave, duration 11ms
Authentication: CCC/CE/FCC/EMC/CB/ROHS
Waterproof: Front panel reaches IP65 protection level
Hardware Configuration:
CPU: I3-6100U / I3-8145U / I3-10110U
CPU frequency: 2.3GHz / 2.1GHz / 2.1GHz
Integrated graphics: Inte HD Graphic 520 / Inte HD Graphic 620 / Intel UHD Graphic 620
RAM: 4G DDR4(Optional 8G/16G/32G) / 4G DDR4(Optional 8G/16G/32G) / 8G DDR4(Optional 16G/32G/64G)
Storage: 128G SSD (Optional 256/512G)
WiFi: 2.4GHz / 5GHz dual bands
Bluetooth: BT4.0(Optional)
Operating system: Windows7/10/11; Ubuntu16.04.7/18.04.5/20.04.3; Centos7.6/7.8; Redhat; Debian; Linux
Other support: Support RTC real-time clock and timing switch
Power parameters:
Input voltage: DC 12V~36V
Static Power: 18W
Delivery
We have a wide range of transportation options to choose from. No matter where you are, our transportation options can meet your needs.
Company Profile
FAQ
Q1.Do you accept OEM / ODM order?
A1:Of course, we have our own R&D team that support customization on motherboard design, test and produce.
Q2:What payment method do you accept?
A2:We accept T/T,MoneyGram,Paypal, Western Union is all ok.
Q3:How long is the warranty of your products?
A3:We offer 2 years warranty for all of our products.
Q4:How many days will samples be finished? And how about the mass production?
A4:Samples will be deliver within 3 working days,after payment received. The leading time of mass production will depend on the quantity.
Q5:If we come to China,can you arrange the visiting to your factory?
A5:We warmly welcome and look forward to your visiting to our factory at any time.
