Key Features:
●Ultra-Slim 3mm Bezel for seamless cabinet integration
●Rugged IP65 Protection with aluminum alloy enclosure
●Efficient Processing (Intel i3-6100U/8145U/10110U CPUs)
●True Industrial Design - Fanless X86 architecture
●High-Speed Connectivity - Dual Gigabit Ethernet
●Wide Voltage Support (12V-36V DC input)
●Enhanced Expandability - Multiple industrial I/Os
✓ Cost-Effective Reliability for industrial applications
✓ Large 17.3" Touch Interface for precise control
✓ Energy-Efficient Performance with Intel i3 CPUs
✓ Easy System Integration with existing equipment
Ideal For:
✔ Manufacturing process control
✔ Equipment monitoring interfaces
✔ Industrial HMI solutions
✔ Facility automation systems
Product Description
Product Size: 17.3"
Non-touch: TPC173-W1000-I3
Capacitive touch: TPC173-W1010-I3
Resistive touch: TPC173-W1020-I3
Screen Parameters:
LCD Size: 17.3" TFT LCD
Resolution: 1920×1080
Viewing Angle: 80/80/60/80 (L/R/U/D)
Colour: 16.7M
Brightness: 300 cd/m2
Contrast ratio: 600:1
Physical Characteristics:
Overall dimensions: W458x H291x D67mm
Size of opening: W441 x H274mm
Interface:
Power interface1: 1*DC 2.5, Supporting 12V-36V power input
Power interface2: 1*Industrial terminal, Supporting 12V-36V power input
HDMI: 1*HDMI, Supporting HDMI data output, Up to 4K
USB: 2*USB 2.0 2*USB 3.0
LAN: 2*LAN, Dual 1000M adaptive Ethernet
AUDIO: 1*Audio Out, Support audio output
SIM: 1*SIM, Supporting various formats (Depending on 3G/4G module)
VGA: 1*VGA
COM: 2*RS232
WiFi antenna: 2*WiFi antenna
POWER: Support (1*POWER)
Grounding post: 1*Grounding post (GND)
Product Reliability:
Working Temperature: -10°C to 60°C
Storage temperature: -20°C to 70°C
Relative humidity: Humidity: 95% Non-Condensing
Vibration protection: IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
Impact protection: IEC 60068-2-27, half sine wave, duration 11ms
Authentication: CCC/CE/FCC/EMC/CB/ROHS
Waterproof: Front panel reaches IP65 protection level
Hardware Configuration:
CPU: I3-6100U / I3-8145U / I3-10110U
CPU frequency:2.3GHz / 2.1GHz / 2.1GHz
Integrated graphics:Inte HD Graphic 520 / Inte HD Graphic 620 / Intel UHD Graphic 620
RAM: 4G DDR4(Optional 8G/16G/32G) / 4G DDR4(Optional 8G/16G/32G) / 8G DDR4(Optional 16G/32G/64G)
Storage: 128G SSD(256G/512G SSD, 1T/2T HDD Optional)
WiFi: Dual band 2.4G&5G
Bluetooth: BT4.0(Optional)
Operating system: Win7/10/11, Ubuntu/Centos/Redhat/Debian/Linux
Other support: Support RTC real-time clock and timing switch
Power parameters:
Input voltage: DC 12V~36V
Static Power: 18W
